n8n Environment Variables: Complete Configuration Reference

---

Environment Variables

What you’ll learn: What n8n environment variables are, why they matter, and how precedence works

Environment variables are key value settings passed to a process at runtime. In n8n, they control behavior without code changes

• Use them across Docker, Compose, and Kubernetes for consistent deploys
• Load sensitive values from secret files with the _FILE pattern to avoid plain text
• Defaults help you start fast, explicit config keeps you stable in prod

How n8n reads config

n8n resolves configuration in a clear order. This helps you know which value wins when the same setting appears in multiple places

flowchart TD
    A[Env Vars] --> B[Config File]
    B --> C[Defaults]
    D{Final Value} --- A
    D --- B
    D --- C

    classDef trigger fill:#e1f5fe,stroke:#01579b
    classDef process fill:#fff3e0,stroke:#ef6c00
    classDef action fill:#e8f5e8,stroke:#2e7d32
    class A trigger
    class B process
    class C process
    class D action

• n8n reads process environment first, then config files, then built in defaults
• The _FILE form tells n8n to read the value from a mounted file, common with secret stores
• Prefer variables for immutable images and repeatable deploys

Precedence rules

1. Environment variables override config files and defaults
2. If both VAR and VAR_FILE are set, the file value wins
3. Keep encryption keys and database passwords in a secret manager, not in source control

Terminology

• Secret manager: a service that stores credentials and rotates them securely
• Connection pool: a cache of database connections reused by the app for efficiency
• mTLS: mutual TLS, client and server present certificates to verify each other

Transition: With precedence understood, let’s map the main configuration surfaces you will tune in production

Config Categories

What you’ll learn: The major config groups and when to use them

Each group maps to a deployment concern. You will combine several in production

• Database: DB_TYPE, DB_POSTGRESDB_* for Postgres or SQLite for local dev
• Execution: EXECUTIONS_*, N8N_CONCURRENCY_PRODUCTION_LIMIT
• Security: N8N_ENCRYPTION_KEY, N8N_BASIC_AUTH_*, N8N_BLOCK_ENV_ACCESS_IN_NODE
• Network: WEBHOOK_URL, N8N_PROTOCOL, N8N_HOST, N8N_PORT, proxy hops
• Scaling and queue: EXECUTIONS_MODE queue, QUEUE_BULL_, REDIS_

Transition: Start with the database, because it unlocks scaling, clustering, and safer upgrades

Database Setup

What you’ll learn: When to choose SQLite vs Postgres and the key variables to configure

SQLite is simple and great for local development. Postgres scales for multi instance and queue mode

Postgres core settings

Variable	Purpose	Example or default
DB_TYPE	Selects database backend	sqlite default, postgresdb for scale
DB_POSTGRESDB_HOST	Postgres host name	postgres
DB_POSTGRESDB_PORT	Postgres port	5432
DB_POSTGRESDB_DATABASE	Database name	n8n or n8n_prod
DB_POSTGRESDB_SCHEMA	Schema name	public
DB_POSTGRESDB_USER	Database user	n8n
DB_POSTGRESDB_PASSWORD or DB_POSTGRESDB_PASSWORD_FILE	Password or file based secret	use a secret file with _FILE

Connection tuning

Variable	Purpose	Typical value
DB_POSTGRESDB_POOL_SIZE	Max pooled connections	10 for queue mode
DB_POSTGRESDB_CONNECTION_TIMEOUT	Connect timeout ms	30000 on slow links
DB_POSTGRESDB_IDLE_CONNECTION_TIMEOUT	Idle timeout ms	60000 for bursty load

TLS and certificates

TLS encrypts traffic to the database. mTLS also validates the client

Variable	Purpose	Typical value
DB_POSTGRESDB_SSL_ENABLED	Enable TLS to Postgres	true for remote or managed
DB_POSTGRESDB_SSL_CA	CA cert path	path to CA cert
DB_POSTGRESDB_SSL_CERT	Client cert	path to client cert
DB_POSTGRESDB_SSL_KEY	Client key	path to client key
DB_POSTGRESDB_SSL_REJECT_UNAUTHORIZED	Verify server cert	true, disable only for tests

When to move to Postgres

• You run multiple n8n instances or workers
• Execution volume grows beyond a single file database
• You need backups, high availability, or read replicas

SQLite	PostgreSQL
Zero setup, file based	Network server, scalable
Great for dev and labs	Required for queue mode at scale
No concurrent writers	Optimized for concurrency

flowchart TD
    A[Start on SQLite] --> B{Add workers}
    B -->|No| C[Stay on SQLite]
    B -->|Yes| D[Move to Postgres]
    D --> E[Enable TLS]

    classDef trigger fill:#e1f5fe,stroke:#01579b
    classDef process fill:#fff3e0,stroke:#ef6c00
    classDef action fill:#e8f5e8,stroke:#2e7d32
    class A trigger
    class B process
    class C action
    class D action
    class E action

Optional schema view to anchor concepts

erDiagram
    Workflow ||--o{ Execution : runs
    Credential ||--o{ Workflow : used_by

    Workflow {
        int id
        string name
        datetime created_at
    }

    Execution {
        int id
        int workflow_id
        datetime started_at
    }

    Credential {
        int id
        string name
        datetime created_at
    }

Transition: With storage chosen, tune execution behavior and data retention for reliability and cost

Execution Tuning

What you’ll learn: How to set timeouts, prune data, and cap concurrency

Runtime and retention

Variable	Purpose	Typical value
EXECUTIONS_MODE	Where jobs run	regular or queue for scale
EXECUTIONS_TIMEOUT	Hard stop per run seconds	3600 to kill loops
EXECUTIONS_TIMEOUT_MAX	Max allowed per workflow seconds	7200 for long jobs
EXECUTIONS_DATA_SAVE_ON_SUCCESS	Save success data	none in prod
EXECUTIONS_DATA_SAVE_ON_ERROR	Save error data	all for incident review
EXECUTIONS_DATA_SAVE_ON_PROGRESS	Save per node progress	true only for deep debug
EXECUTIONS_DATA_PRUNE	Enable pruning	true in prod
EXECUTIONS_DATA_MAX_AGE	Keep data hours	168 for one week
EXECUTIONS_DATA_PRUNE_MAX_COUNT	Max records kept	50000 high volume
EXECUTIONS_DATA_MANUAL_EXECUTIONS_SAVE	Save manual runs	false in prod
N8N_CONCURRENCY_PRODUCTION_LIMIT	Max concurrent executions	20 to prevent spikes

Quick tips

• Start with strict timeouts in prod and relax per workflow as needed
• Save minimal success data, keep errors for root cause analysis

Transition: Next, lock down credentials and tighten surface area

Security basics

What you’ll learn: How to protect stored credentials and restrict access

Variable	Purpose	Typical value
N8N_ENCRYPTION_KEY or N8N_ENCRYPTION_KEY_FILE	Encrypt stored credentials	set before first prod boot
N8N_BASIC_AUTH_ACTIVE	Gate the UI with Basic Auth	true for small teams
N8N_BASIC_AUTH_USER	Basic Auth user name	admin or team user
N8N_BASIC_AUTH_PASSWORD	Basic Auth password	a long random string
N8N_BLOCK_ENV_ACCESS_IN_NODE	Block env reads in Code node	true for shared installs
NODES_EXCLUDE or NODES_INCLUDE	Disable or allowlist node ids	reduce attack surface
N8N_COMMUNITY_PACKAGES_ENABLED	Allow community packages	false for hardened clusters

Definitions

• Basic Auth: browser prompt for user and password before loading the app
• Allowlist: only listed items are permitted, all others are blocked

Security stance

1. Set and persist N8N_ENCRYPTION_KEY before storing any credentials
2. Block environment access for untrusted builders
3. Disable risky nodes you do not need

Transition: Finally, make sure webhooks resolve correctly behind reverse proxies

Network and webhooks

What you’ll learn: How to make public URLs and client IPs resolve correctly

Variable	Purpose	Typical value
N8N_HOST	Host name for URLs	n8n.example.com
N8N_PORT	Internal port	5678
N8N_PROTOCOL	URL scheme	https behind a proxy
WEBHOOK_URL	External base URL override	public https address
N8N_PROXY_HOPS	Trusted proxy hops count	match proxy chain

Common setup

• Terminate TLS on Nginx or Traefik
• Set WEBHOOK_URL to the public https URL
• Keep N8N_PORT at 5678 internally

Symptom	Likely cause	Fix
Webhooks show localhost	Missing WEBHOOK_URL	Set the public https URL
Wrong client IP or scheme	Proxy hops not trusted	Set N8N_PROXY_HOPS to match chain

flowchart TD
    A[Client] --> B[Proxy]
    B --> C[n8n]
    C --> D[Webhook Flow]

    classDef trigger fill:#e1f5fe,stroke:#01579b
    classDef process fill:#fff3e0,stroke:#ef6c00
    classDef action fill:#e8f5e8,stroke:#2e7d32
    class A trigger
    class B process
    class C process
    class D action

Transition: When load grows, switch to queue mode and scale workers

Queue mode

What you’ll learn: How to enable distributed workers with Redis

• Redis is an in memory data store used here as a job queue
• Worker is a process that pulls jobs from the queue and executes workflows

Variable	Purpose	Typical value
EXECUTIONS_MODE	Execution backend	queue to distribute load
QUEUE_BULL_REDIS_HOST	Redis host name	redis service name
QUEUE_BULL_REDIS_PORT	Redis port	6379
REDIS_HOST and REDIS_PORT	Alternative Redis vars	use if your image expects them
REDIS_PASSWORD or REDIS_PASSWORD_FILE	Redis password or file	required on secured Redis
QUEUE_WORKER_CONCURRENCY	Jobs per worker	tune by CPU and memory
N8N_DISABLE_PRODUCTION_MAIN_PROCESS	Disable main duties	true for worker only containers

flowchart TD
    A[Main] --> B[Redis]
    B --> C[Worker 1]
    B --> D[Worker 2]
    C --> E[Run Jobs]
    D --> E

    classDef trigger fill:#e1f5fe,stroke:#01579b
    classDef process fill:#fff3e0,stroke:#ef6c00
    classDef action fill:#e8f5e8,stroke:#2e7d32
    class A trigger
    class B process
    class C process
    class D process
    class E action

Starter Env

What you’ll learn: A copy paste .env for Postgres and queue mode to get you production ready

Minimal production .env example

# ---- Identity and URLs ----
N8N_HOST=n8n.example.com
N8N_PORT=5678
N8N_PROTOCOL=https
WEBHOOK_URL=https://n8n.example.com/

# ---- Security ----
# Generate once and store in a secret manager, 64 hex chars
N8N_ENCRYPTION_KEY=YOUR_64_HEX_SECRET
N8N_BLOCK_ENV_ACCESS_IN_NODE=true
N8N_BASIC_AUTH_ACTIVE=true
N8N_BASIC_AUTH_USER=admin
N8N_BASIC_AUTH_PASSWORD=change-me-now

# ---- Database Postgres ----
DB_TYPE=postgresdb
DB_POSTGRESDB_HOST=postgres
DB_POSTGRESDB_PORT=5432
DB_POSTGRESDB_DATABASE=n8n
DB_POSTGRESDB_SCHEMA=public
DB_POSTGRESDB_USER=n8n
DB_POSTGRESDB_PASSWORD_FILE=/run/secrets/db_password
DB_POSTGRESDB_POOL_SIZE=10
DB_POSTGRESDB_CONNECTION_TIMEOUT=30000
DB_POSTGRESDB_IDLE_CONNECTION_TIMEOUT=60000
DB_POSTGRESDB_SSL_ENABLED=false

# ---- Executions and retention ----
EXECUTIONS_MODE=queue
EXECUTIONS_TIMEOUT=3600
EXECUTIONS_TIMEOUT_MAX=7200
EXECUTIONS_DATA_SAVE_ON_SUCCESS=none
EXECUTIONS_DATA_SAVE_ON_ERROR=all
EXECUTIONS_DATA_SAVE_ON_PROGRESS=false
EXECUTIONS_DATA_PRUNE=true
EXECUTIONS_DATA_MAX_AGE=168
EXECUTIONS_DATA_PRUNE_MAX_COUNT=50000
N8N_CONCURRENCY_PRODUCTION_LIMIT=20

# ---- Queue and Redis ----
QUEUE_BULL_REDIS_HOST=redis
QUEUE_BULL_REDIS_PORT=6379
# REDIS_PASSWORD_FILE=/run/secrets/redis_pw
QUEUE_WORKER_CONCURRENCY=5

TZ=UTC

Optional extras

# Use mTLS to Postgres
DB_POSTGRESDB_SSL_ENABLED=true
DB_POSTGRESDB_SSL_CA=/certs/ca.pem
DB_POSTGRESDB_SSL_CERT=/certs/client.crt
DB_POSTGRESDB_SSL_KEY=/certs/client.key
DB_POSTGRESDB_SSL_REJECT_UNAUTHORIZED=true

# Worker only container
N8N_DISABLE_PRODUCTION_MAIN_PROCESS=true

Transition: If something breaks, use the checklist below to zero in fast

Debugging

What you’ll learn: How to diagnose the most common misconfigurations

Lost credentials after restart

• Cause: N8N_ENCRYPTION_KEY was auto generated and lost during redeploy
• Fix: Set a persistent N8N_ENCRYPTION_KEY or N8N_ENCRYPTION_KEY_FILE before storing credentials and back it up

Wrong webhook URLs behind proxies

• Cause: WEBHOOK_URL unset, N8N_PROTOCOL wrong, or proxy hops not trusted
• Fix: Set WEBHOOK_URL to the public https URL, set N8N_PROTOCOL to https, set N8N_PROXY_HOPS to match your chain

Database connection or pool issues

• Cause: Pool too small, wrong host or port, or TLS mismatch
• Fix: Verify DB_POSTGRESDB_* values, raise DB_POSTGRESDB_POOL_SIZE gradually, and match TLS to the server

Execution data bloat

• Cause: Saving all success data or pruning disabled
• Fix: Set EXECUTIONS_DATA_SAVE_ON_SUCCESS to none and enable pruning with sane age and count

Queue jobs stuck in running

• Cause: Redis unreachable, wrong host, or no worker running
• Fix: Point QUEUE_BULL_REDIS_HOST to the correct service, confirm ports, and start at least one worker with valid DB and Redis env

Checklist

What you’ll learn: A fast order of operations for safe rollouts

1. Set and persist N8N_ENCRYPTION_KEY before first prod boot
2. Use Postgres and queue mode for multi instance or high volume setups
3. Always set WEBHOOK_URL behind a proxy and use https
4. Enable pruning and keep success data to a minimum
5. Tune Postgres pool and worker concurrency using real metrics
